Cold Cutting & Beveling
The Hydratight NB or Narrow Body portable Clamshell series are ideal when space is at a premium. Each of the machines within the NB series have a height of 76.2 mm (3”) and a width of 57.2 mm (2.25”).The resulting narrow body low profile design makes the NB series the perfect choice in tight spaces or if obstructions are present. Available from Pipe size 4″ – 24″ (114 – 609 mm).
- 5 Standard models cover a range from 50.8 mm (2.0″) to 914.4 mm (36″) OD
- Pneumatic, hydraulic and electric drive options provide increased versatility
- Stepped and keyed gear clamps equipped with a through bolt provide a positive fit at each
assembly joint
- Fully adjustable heavy duty bearing design provides greater serviceability
- NB series clamshells accept a wide range of accessories to increase performance and expand capabilities
- Locator extensions are compatable with the
MS series clamshells
- Several different drive options are available to
best position the motor for a specific machining application
